Detailed Description
Holds the initialization parameters required for the NvDsPostProcessContext interface.
Definition at line 262 of file post_processor_struct.h.
Data Fields | |
| unsigned int | uniqueID |
| Holds a unique identifier for the instance. More... | |
| unsigned int | maxBatchSize |
| Holds the maximum number of frames to be inferred together in a batch. More... | |
| char | labelsFilePath [_PATH_MAX] |
| Holds the pathname of the labels file containing strings for the class labels. More... | |
| NvDsPostProcessNetworkType | networkType |
| Holds the network type. More... | |
| unsigned int | numDetectedClasses |
| Holds the number of classes detected by a detector network. More... | |
| NvDsPostProcessDetectionParams * | perClassDetectionParams |
| Holds per-class detection parameters. More... | |
| float | classifierThreshold |
| Holds the minimum confidence threshold for the classifier to consider a label valid. More... | |
| float | segmentationThreshold |
| char ** | outputLayerNames |
| Holds a pointer to an array of pointers to output layer names. More... | |
| unsigned int | numOutputLayers |
| Holds the number of output layer names. More... | |
| unsigned int | gpuID |
| Holds the ID of the GPU which is to run the inference. More... | |
| NvDsInferDimsCHW | inferInputDims |
| Inference input dimensions for runtime engine. More... | |
| NvDsPostProcessClusterMode | clusterMode |
| Holds the type of clustering mode. More... | |
| char | customBBoxInstanceMaskParseFuncName [_MAX_STR_LENGTH] |
| Holds the name of the bounding box and instance mask parse function in the custom library. More... | |
| char | customBBoxParseFuncName [_MAX_STR_LENGTH] |
| Holds the name of the custom bounding box function in the custom library. More... | |
| char | customClassifierParseFuncName [_MAX_STR_LENGTH] |
| Name of the custom classifier attribute parsing function in the custom library. More... | |
| NvDsPostProcessTensorOrder | segmentationOutputOrder |
| Holds output order for segmentation network. More... | |
| char * | classifier_type |
| gboolean | preprocessor_support = FALSE |
| Holds boolean value to show whether preprocessor support is there. More... | |
Field Documentation
◆ classifier_type
| char* _NvDsPostProcessContextInitParams::classifier_type |
Definition at line 323 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ classifierThreshold
| float _NvDsPostProcessContextInitParams::classifierThreshold |
Holds the minimum confidence threshold for the classifier to consider a label valid.
Definition at line 291 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ clusterMode
| NvDsPostProcessClusterMode _NvDsPostProcessContextInitParams::clusterMode |
Holds the type of clustering mode.
Definition at line 307 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ customBBoxInstanceMaskParseFuncName
| char _NvDsPostProcessContextInitParams::customBBoxInstanceMaskParseFuncName[_MAX_STR_LENGTH] |
Holds the name of the bounding box and instance mask parse function in the custom library.
Definition at line 311 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ customBBoxParseFuncName
| char _NvDsPostProcessContextInitParams::customBBoxParseFuncName[_MAX_STR_LENGTH] |
Holds the name of the custom bounding box function in the custom library.
Definition at line 315 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ customClassifierParseFuncName
| char _NvDsPostProcessContextInitParams::customClassifierParseFuncName[_MAX_STR_LENGTH] |
Name of the custom classifier attribute parsing function in the custom library.
Definition at line 318 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ gpuID
| unsigned int _NvDsPostProcessContextInitParams::gpuID |
Holds the ID of the GPU which is to run the inference.
Definition at line 301 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ inferInputDims
| NvDsInferDimsCHW _NvDsPostProcessContextInitParams::inferInputDims |
Inference input dimensions for runtime engine.
Definition at line 304 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ labelsFilePath
| char _NvDsPostProcessContextInitParams::labelsFilePath[_PATH_MAX] |
Holds the pathname of the labels file containing strings for the class labels.
The labels file is optional. The file format is described in the custom models section of the DeepStream SDK documentation.
Definition at line 276 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ maxBatchSize
| unsigned int _NvDsPostProcessContextInitParams::maxBatchSize |
Holds the maximum number of frames to be inferred together in a batch.
The number of input frames in a batch must be less than or equal to this.
Definition at line 271 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ networkType
| NvDsPostProcessNetworkType _NvDsPostProcessContextInitParams::networkType |
Holds the network type.
Definition at line 280 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ numDetectedClasses
| unsigned int _NvDsPostProcessContextInitParams::numDetectedClasses |
Holds the number of classes detected by a detector network.
Definition at line 283 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ numOutputLayers
| unsigned int _NvDsPostProcessContextInitParams::numOutputLayers |
Holds the number of output layer names.
Definition at line 298 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ outputLayerNames
| char** _NvDsPostProcessContextInitParams::outputLayerNames |
Holds a pointer to an array of pointers to output layer names.
Definition at line 296 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ perClassDetectionParams
| NvDsPostProcessDetectionParams* _NvDsPostProcessContextInitParams::perClassDetectionParams |
Holds per-class detection parameters.
The array's size must be equal to numDetectedClasses.
Definition at line 287 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ preprocessor_support
| gboolean _NvDsPostProcessContextInitParams::preprocessor_support = FALSE |
Holds boolean value to show whether preprocessor support is there.
Definition at line 325 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ segmentationOutputOrder
| NvDsPostProcessTensorOrder _NvDsPostProcessContextInitParams::segmentationOutputOrder |
Holds output order for segmentation network.
Definition at line 321 of file post_processor_struct.h.
◆ segmentationThreshold
| float _NvDsPostProcessContextInitParams::segmentationThreshold |
Definition at line 293 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
◆ uniqueID
| unsigned int _NvDsPostProcessContextInitParams::uniqueID |
Holds a unique identifier for the instance.
This can be used to identify the instance that is generating log and error messages.
Definition at line 266 of file post_processor_struct.h.
Referenced by PostProcessAlgorithm::PostProcessAlgorithm().
The documentation for this struct was generated from the following file:
